About this Item
CameraImage-sensor 1/3" progressive scan CMOS Min. Illumination Color: 0.01Lux @(F1.2,AGC ON),0 Lux with IR Shutter Speed 1/3s to 1/100,000s, slow shutter support lens 2.8mm to 12mm @F1.4, horizontal field of view: 108° to 31° Lens Mount Φ14 Day&Night IR cut filter with auto switch 3-Axis Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360° DNR (Digital Noise Reduction) 3D DNRWDR (Wide Dynamic Range) 120dB Compressionvideo compression Mainstream: H.264+/H.264 Substream: H.264/MJPEG H.264 Type Main profile/High profile Video Bit Rate 32 Kbps to 16 MbpsImageMax. Resolution 2688×1520 Main StreamMax. Frame Rate50Hz:20fps@(2688×1520), 20fps@(2304×1296), 25fps@(1920×1080, 1280×720)60Hz:20fps@(2688×1520), 20fps@(2304×1296), 30fps@(1920×1080, 1280×720) Sub-streamMax. Frame Rate 50Hz: 25fps @(640×360, 352×288)60Hz: 30fps @(640×360, 352×240) Picture Settings Brightness, saturation, contrast, sharpness are adjustable via web browser or client software Day/Night Switch Support auto, scheduled others Mirror, BLC (configurable area), region of interest (support 1 fixed region)NetworkNetwork Storage Support micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR Detections motion detection Alarms Video tampering, network disconnected, IP address conflicted, HDD full, HDD error Protocols TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour Standard ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI General Function One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filterInterface Communications Interface 1 RJ45 10M/100M self-adaptive Ethernet port Video Output (Without-Z) 1Vp-p composite output(75Ω/BNC) Reset SupportGeneralOperating Conditions -30°C to60°C (-22°F to140°F), humidity: 95% or less (non-condensing) power-supply DC12V±25%, PoE (802.3af) power consumption Max. 5.5W/11W (With-Z) Protection Level IP67, IK10 IR Range Up to 30m Dimensions Φ141mm×99.9mm (5.6"×3.9") Weight 800 g (1.76 lbs.)
