About this Item
【Specification】 Material: ABS : Black+Orange Display: LCD screen Batt Voltage: 12v/24v auto Rated Current: 10A Self-consumption: ＜10MA Working temperature: -35 ℃ -60 ℃ solar input: 12v , the highest 23v; 24v when the highest 46v Float charge: 13.7v(defaul, adjustable) Discharge stop: 10.7v(defaul, adjustable) Discharge reconnect: 12.6v(defaul, adjustable) Charge reconnect: 13v Voltage of open light: solar panel 8v(Light lights delay) Voltage of close light: Solar panel 8v(Light off delay) USB output: 2 way USB output, 5V/2.5A() Size: (L)X(W)X(H)133.5X70X35mm /5.26''X2.76''X1.38"(appr.) 【Features】 ? Build-in industrial micro controller ? Fully 3-stage PWM charge management ? Big LCD display, all adjustable ? Dual mosfet current protection, low heat production ? Dual USB output, the maximum current of 2.5A, to 's mobile phone charging ? Build-in short-circuit protection, open-circuit protection, protection, over-load protection ? Suitable for solar green light, solar light boxes advertising board, solar insecticidal lights, housing solar generation system, marine solar generation system, outdoor survival solar generation system SAFETY INSTRUCTIONS 1.Make sure your has enough voltage for the controller to recognize the type before first installation 2.The cable should be as short as possible to minimize loss 3.The regulator is suitable for lead acid batteries: OPEN,AGM,, it is not suited for nickel metal hydride, ions or batteries 4.The charge regulator is suitable for regulating solar modules. Never connect another charging source to the charge regulator SYSTEM CONNECTION 1.Connect the to the charge regulator-plus and minus 2.Connect the photovoltaic module to the regulator-plus and minus 3.Connect the consumer to the regulator-plus and minus The order applies when deinstalling An improper sequence order can damage the controller 【Notice】 - Please allow slight dimension difference due to manual measurement. - Please consider the actual sizes in the listing as the pictures are generally enlarged to show detail. - Due to different producing batches, product details might be a little different. If you minding the difference, please buy it carefully. - Due to the light and screen difference, the item's may be slightly different from the pictures. Thanks for your understanding. a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a
